Product Description
Product Introduction
Inner Container Material
Made of high-density polyethylene (HDPE) produced through blow-molding, ensuring seamless construction and exceptional strength.
Features excellent resistance to acids, alkalis, and salts, along with high heat and cold tolerance (operating temperature range: -40°C to 60°C).
Provides strong tensile strength, hardness, and electrical insulation, with a wall thickness of approximately 2.0–2.5 mm for enhanced durability.
External Structure
Outer cage is constructed from hot-dip galvanized steel pipes (typically 40mm diameter) welded into a grid pattern, offering impact resistance and structural integrity.
Equipped with a four-way entry European standard all-steel pallet (size: 1200mm x 1000mm) for safe and stable forklift handling.
The cage design allows secure stacking of up to 4 units high when fully loaded.
Capacity & Dimensions
Total volume: 500 liters (132 gallons).
Standard dimensions: 1200mm (L) x 1000mm (W) x 1160mm (H).
Tare weight: approximately 55–60 kg, with a maximum gross weight of 600 kg when filled.
Performance & Safety Features
Designed to meet UN certification for the transport of hazardous liquids (Class II/III chemicals).
Includes a standard 2-inch butterfly valve and 3-inch filler cap, both with secure sealing to prevent leaks.
The reinforced base and steel frame ensure stability during transport and storage, even under dynamic loads.
Production & Supply
Manufacturing capacity of up to 600 units per day, enabling fast order fulfillment.
Regular stock maintained for urgent requirements, ensuring reliable and timely delivery.
Applications
Widely used in chemical, pharmaceutical, food, beverage, dye, pesticide, and water treatment industries.
Suitable for storing and transporting hazardous materials, viscous liquids, and food-grade products.
Commonly applied in high-rise building secondary water supply, electronic industry fluid storage, and environmental purification systems.
Frequently Asked Questions
What materials are used to construct the inner container and external cage?
The inner container is made of high-density polyethylene (HDPE) via seamless blow-molding with a wall thickness of 2.0–2.5 mm. The outer cage is constructed from durable, hot-dip galvanized steel pipes welded in a protective grid pattern.
What is the total capacity and maximum load weight of the unit?
The container has a total volume of 500 liters (132 gallons). Its tare weight is approximately 55–60 kg, and it supports a maximum gross weight of up to 600 kg when fully loaded.
Is this container suitable for hazardous materials and chemical storage?
Yes, it is designed to meet UN certification standards for transporting Class II and Class III hazardous chemicals, featuring high chemical resistance against acids, alkalis, and salts.
What temperature range can the container withstand?
The HDPE inner container offers exceptional thermal tolerance, operating safely in ambient and liquid temperature ranges from -40°C to 60°C.
How high can these containers be stacked during storage and transport?
Thanks to the reinforced steel grid structure and European standard all-steel pallet base, fully loaded containers can be safely stacked up to 4 units high.
What is your daily production capacity for urgent orders?
We maintain a manufacturing capacity of up to 600 units per day and keep regular stock available to support rapid delivery and urgent industrial demands.
